Milesight 48VDC UK Plug Adapter For UR32 POE

Milesight 48V Power Supply for UR32 PoE Routers

The Milesight KT241480050BS is the 48V power supply required when using the Power over Ethernet output on compatible UR32 series routers. The standard UR32 ships with a 12V DC adapter, which is sufficient for running the router itself. However, PoE output to connected devices requires a 48V supply – this unit is the correct replacement.

It is a wall-mount, UK plug design with a 1.5m cable and an industrial 5mm pitch terminal connector, matching the UR32’s power input. Built-in 2kV surge protection adds a layer of resilience in industrial environments where transient spikes on the mains supply are a real risk.

Key specifications

• Part number: KT241480050BS
• Output: 48 VDC, 0.5 A
• Connector: Industrial terminal connector, 5mm pitch
• Cable length: 1.5 m
• Mount type: Wall-mount, UK plug
• Surge protection: 2kV
• Dimensions: 79.4 x 42.5 x 31.7 mm
• Certifications: CE, FCC
• Colour: Black

Which UR32 routers need this power supply?

Not every UR32 variant includes a PoE output port. The models listed below are the ones currently available on routerstore.com that support PoE out – and all of them require this 48V supply to activate that function.

• Milesight UR32L-L0GEU-P – 4G Router with PoE – the compact UR32L variant with a single PoE LAN port, suited to installations where a single downstream device needs powering alongside the router
• Milesight UR32-L0GEU-P-W-485 – 4G Router with PoE, Wi-Fi and RS485 – adds dual-band Wi-Fi and an RS485 serial port to the PoE model, useful where legacy serial devices share the same installation
• Milesight UR32 Pro Series – UR32-L0GEU-P-W-485 – the Pro tier of the same configuration, with enhanced processing and expanded VPN and management capabilities for more demanding deployments

If you are unsure which UR32 you have, check the label on the underside of the unit. Models with a -P- in the part number include the PoE port. If your model does not have -P- in the code, PoE output is not supported regardless of power supply voltage.

FAQ

Can I use a different 48V power supply?

You can use any 48V DC supply that matches the terminal connector pitch (5mm) and delivers at least 0.5A. That said, this unit is the Milesight-specified accessory for the UR32 range and includes the correct connector out of the box. Using an unspecified supply may affect warranty cover.

Does this power supply replace the one in the box?

Yes. The UR32 ships with a 12V adapter for standard operation. If you need PoE output, swap to this 48V unit. The router itself runs on either voltage – the difference is whether the PoE port is active.

Is this suitable for outdoor installations?

This is a wall-mount indoor supply. For outdoor enclosure installations, the supply should be mounted inside a rated enclosure alongside the router. The 1.5m cable gives reasonable routing flexibility within a cabinet or panel.
