Teltonika RUTM55 5G Router
Teltonika RUTM55
The Teltonika RUTM55 (RUTM55000000) is an industrial 5G router with Dual-SIM + eSIM, RS232/RS485, digital and analogue I/O, 4× Gigabit Ethernet, dual-band Wi-Fi 5, and GNSS. Rugged aluminium housing, wide voltage input, and –40…+75 °C operation make it ideal for SCADA, utilities, transport and remote monitoring.
Key Features
- 5G Sub-6 (SA/NSA): up to 3.4 Gbps downlink with LTE Cat 19 fallback
- Dual-SIM + eSIM: intelligent failover and multiple carrier profiles
- Legacy ports: RS232 and RS485 for PLCs and older controllers
- I/O block: digital inputs, analogue input, open-collector output and relay
- 4× Gigabit Ethernet: 1× WAN (configurable) + 3× LAN
- Dual-band Wi-Fi 5: fast local access, up to 867 Mbps
- GNSS: GPS, GLONASS, BeiDou, Galileo, QZSS with NMEA/NTRIP and geofencing
- Secure networking: OpenVPN, WireGuard, IPsec, firewall, VLANs, certificate management
- Fleet-ready: remote management, FOTA, secure device access via RMS
- Industrial design: anodised aluminium housing, IP30, –40…+75 °C, 9–50 VDC input
£381.00 Excl VAT
The RUTM55 is Teltonika’s workhorse 5G router for sites that need modern bandwidth without abandoning legacy equipment. It combines sub-6 5G (SA/NSA) performance with native RS232/RS485 and a full I/O block so PLCs, HMIs and sensors can be brought online without extra gateways.
For resilience, you get Dual-SIM and eSIM with intelligent switch rules (signal, roaming, quotas, link failure) plus the option to use one of the Gigabit ports as Ethernet WAN for wired backup. Local access is handled by dual-band Wi-Fi 5 and 4× Gigabit LAN, while GNSS provides positioning, time sync or geofencing.
Security and fleet control are first-class: OpenVPN, WireGuard, IPsec, firewall/VLANs, certificate management and remote provisioning and monitoring via Teltonika’s management tools. The compact anodised aluminium chassis, IP30 rating and –40…+75 °C temperature range make it at home in panels, cabinets and plant rooms.
Key Features
- Industrial 5G (SA/NSA): high throughput with 4G LTE fallback
- Dual-SIM + eSIM: carrier diversity with granular, rule-based failover
- Legacy integration: RS232 + RS485 on terminal blocks, plus DI/AI/DO and relay
- 4× Gigabit Ethernet: 1× WAN (configurable) + 3× LAN for flexible topologies
- Dual-band Wi-Fi 5: fast local access or client mode uplinks
- GNSS onboard: GPS/GLONASS/BeiDou/Galileo/QZSS with NMEA/NTRIP and geofencing
- Secure networking: OpenVPN, IPsec, WireGuard, VLANs, firewall, 802.1X
- Fleet-ready: zero-touch provisioning, FOTA, and remote device access
- Rugged build: anodised aluminium, IP30, –40…+75 °C, 9–50 VDC power input
- Installer-friendly I/O: clear terminal blocks, SMA/RP-SMA antenna connectors, DIN-rail/wall mounting
Typical Applications
- SCADA/PLC retrofit: bring serial-only controllers onto secure IP networks via 5G
- Energy & utilities: substations, telemetry, AMI/AMR, remote outstations
- Industrial automation: machine data, OT visibility, vendor remote support
- Transport & telematics: GNSS-enabled tracking, mobile data backhaul, depot Wi-Fi
- Retail/branch resilience: 5G primary or failover WAN with policy routing/load-balance
- Remote monitoring & control: private APN/VPN access to cameras, sensors, and HMIs
Why Choose the RUTM55
- One box, fewer points of failure: router and serial gateway and I/O in a single unit
- Designed for uptime: Dual-SIM, eSIM, Ethernet WAN and rule-based switching
- Built for harsh sites: wide power range, wide temperature, metal enclosure
- Secure by design: modern VPNs, certificate automation, fleet management at scale
Technical Highlights (at a glance)
- 5G sub-6 (SA/NSA), 4G LTE fallback
- Dual-SIM + eSIM (multiple profiles)
- 4× GbE (1× WAN configurable)
- Wi-Fi 5 (dual-band, MU-MIMO)
- RS232, RS485, DI, AI, DO, relay
- GNSS (GPS/GLONASS/BeiDou/Galileo/QZSS)
- 9–50 VDC input, IP30, –40…+75 °C
The optional power supply for the RUTM55 is the PR315UKA
Teltonika RUTM55 Specification
| Category | Item | Details |
|---|---|---|
| Mobile | Mobile module | 5G Sub-6 GHz SA/NSA, DL up to 3.4 Gbps (4×4 MIMO), UL up to 900/550 Mbps (2×2 MIMO); LTE Cat 19 DL up to 1.6 Gbps (4×4 MIMO), Cat 18 UL up to 200 Mbps |
| 3GPP Release | Release 16 | |
| eSIM | Consumer type eSIM, profile download/removal, up to 7 profiles (no data plan included) | |
| SIM | 2 × Mini-SIM (2FF) slots, Dual SIM + eSIM with automatic switching | |
| SIM switching | Auto cases: weak signal, data limit, SMS limit, roaming, no network, network denied, connection fail, idle protection | |
| Status info | IMSI, ICCID, operator/state, connection state, network type, CA, bandwidth, connected band, RSSI, RSRP, RSRQ, SINR, EC/IO, RSCP, data counters, LAC, TAC, cell ID, ARFCN/UARFCN/EARFCN, MCC, MNC | |
| SMS/USSD | Full SMS management (send, receive, forward, schedule, SMPP), USSD supported | |
| Operator control | Block/allow list by country/operator | |
| Band management | Band-lock, used band display | |
| APN | Auto APN supported | |
| Modes | Bridge, Passthrough, Framed Routing | |
| Wireless | Mode | 802.11 b/g/n/ac Wave 2 (Wi-Fi 5), dual-band, MU-MIMO, up to 867 Mbps |
| Security | WPA2-Enterprise, WPA2-PSK, WPA3-SAE/EAP, OWE, AES-CCMP/TKIP, 802.11w PMF | |
| Clients | Up to 150 simultaneous | |
| Features | Mesh (802.11s), fast roaming (802.11r), BSS-TM (802.11v), 802.11k RRM, MAC filter, SSID stealth, QR join | |
| Ethernet | WAN | 1 × 10/100/1000 Mbps RJ45 |
| LAN | 3 × 10/100/1000 Mbps RJ45 | |
| Standards | IEEE 802.3, 802.3u, 802.3az, auto MDI/MDIX | |
| Network | Routing | Static, Dynamic (BGP, OSPFv2, RIP v1/v2, EIGRP, NHRP), Policy-based |
| Protocols | TCP, UDP, IPv4/IPv6, ICMP, NTP, DNS, HTTP/HTTPS, FTP/SFTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPnP, SSH, DHCP, Telnet, SNMP, MQTT, SMPP | |
| VoIP passthrough | H.323 and SIP helpers | |
| Monitoring | Ping reboot, Wget reboot, periodic reboot, LCP/ICMP check | |
| Firewall | Port forwarding, traffic/custom rules, DMZ, NAT/NAT-T, TTL control | |
| Hotspot | Captive portal, RADIUS, SMS auth, SSO, walled garden, user groups, custom themes | |
| DHCP | Server, relay, static leases | |
| QoS | Traffic priority queues, WMM, 802.11e SQM | |
| DDNS | >77 providers supported | |
| DNS | DNS over HTTPS (DoH) | |
| Resilience | Automatic failover (mobile, wired, Wi-Fi, VRRP), load balancing | |
| VRF | Supported | |
| Traffic mgmt | Real-time monitoring, usage history, wireless charts | |
| Security | Authentication | Pre-shared key, certificates, RADIUS, TACACS+, 802.1X |
| Protection | DDoS/port scan prevention, brute force blocking | |
| VLAN | Port/tag-based VLANs | |
| Web filter | Blacklist/whitelist | |
| TPM | TPM 2.0 module | |
| Certificates | Let’s Encrypt supported | |
| VPN | OpenVPN | Multiple clients/servers, 27 encryption methods |
| IPsec | IKEv1/v2, 14 encryption methods including AES-GCM | |
| Other | GRE(/IPsec), PPTP, L2TP(/IPsec), L2TPv3, Stunnel, DMVPN, SSTP client, ZeroTier, WireGuard (client/server), Tinc, Tailscale | |
| Industrial Protocols | OPC UA | Client/server over TCP |
| Modbus | Client/server over TCP & USB, custom register blocks | |
| DNP3 | TCP master, outstation | |
| DLMS/COSEM | Client, TCP | |
| Data to server | HTTP(S), MQTT, Azure MQTT, Lua scripting | |
| MQTT gateway | Modbus-MQTT bridge | |
| Management | Interfaces | WebUI, CLI/SSH, SMS/USSD, HTTP API, SNMP v1/v2/v3, TR-069, RMS |
| Logs | Event/system/kernel logs, multiple syslog servers | |
| FOTA | Firmware update from file, server or RMS | |
| Profiles | Config profiles, backup/restore, keep settings | |
| SDK | Custom firmware, branding, Lua/C/C++/Python support, Package Manager | |
| Location | GNSS | GPS, GLONASS, BeiDou, Galileo, QZSS |
| Features | NMEA 0183, NTRIP client, coordinates via WebUI/SMS/RMS, geofencing | |
| Serial & USB | RS232 | TX, RX via terminal block |
| RS485 | A, B (2-wire) | |
| Functions | Console, Serial-over-IP, Modbus gateway, NTRIP client | |
| USB 2.0 | External storage/modems/printers, USB-serial adapter, FAT/FAT32/exFAT/NTFS (RO)/ext2/3/4 | |
| I/O | Inputs | 1 × digital dry input (0–3 V), 1 × galvanically isolated input (0–50 V), 1 × analogue input (0–24 V) |
| Outputs | 1 × isolated open-collector (50 V, 500 mA), 1 × SPST relay (24 V, 10 A) | |
| Events | Trigger email, SMS, RMS actions; I/O juggler | |
| Power | Connector | 3-pin pluggable terminal block |
| Range | 9–50 VDC, surge/reverse polarity protection | |
| PoE | Passive PoE-in on LAN1 (9–50 VDC, Mode B); not IEEE 802.3af/at/bt | |
| Consumption | < 8.5 W idle, < 14.5 W max | |
| Physical Interfaces | Ethernet | 4 × RJ45 Gigabit |
| SIM | 2 × Mini-SIM (2FF), 1 × eSIM | |
| Antennas | 4 × SMA (mobile), 2 × RP-SMA (Wi-Fi), 1 × SMA (GNSS) | |
| USB | 1 × USB A host | |
| Serial | RS232 + RS485 via 16-pin terminal block | |
| I/O | Digital/analogue inputs, OC output, relay | |
| LEDs | 3 × mobile type, 3 × signal bars, 6 × LAN, 1 × power | |
| Reset | Reboot, user default, full factory | |
| Hardware | CPU | MediaTek dual-core 880 MHz (MIPS1004Kc) |
| RAM | 256 MB DDR3 | |
| Flash | 16 MB NOR + 256 MB NAND | |
| Physical | Housing | Anodised aluminium |
| Size | 132 × 44.2 × 95 mm | |
| Weight | 430 g | |
| Mounting | DIN-rail, wall, flat (kits required) | |
| Ingress | IP30 | |
| Operating temp | –40 °C to +75 °C | |
| Humidity | 10–90 % RH non-condensing | |
| Compliance | Regulatory | CE, UKCA, CB, RCM, EAC, UCRF, WEEE |
Standard package*
- RUTM55 Router
- 3-pin power connector
- 2X8PIN Connector
- Hex key
- SIM Adapter kit
- QSG (Quick Start Guide)
- Packaging box
*Standard package contents may differ based on standard order codes.
classification codes
HS Code: 851762
HTS: 8517.62.00
For more information on all available packaging options – please contact us directly.
AVAILABLE VERSIONS
RUTM55 0*****
EMEA1, APAC, Brazil
5G NR NSA: n1, n3, n7, n38, n40, n41, n71, n77, n78
5G NR SA: 5G NR SA: n1, n3, n7, n38, n40, n41, n71, n77, n78
4G (LTE-FDD): B1, B3, B7, B38, B40, B41, B42, B43, B71
4G (LTE-TDD): B1, B3, B7, B38, B40, B41, B42, B43, B71
3G: B1, B3, B5, B8
RUTM55000000 / Standard package
Hardware version
Supported frequencies
Standard order code / Package Contains
The price and lead-times for region (operator) specific versions may vary.
1 - Regional availability - excluding Russia, Belarus & Iran 2 - For more detailed information about certified carriers, visit the Teltonika Wiki page
